A hybrid ATSCUSB 2.0 device by Hauppauge.

Download the WinTV-HVR-900 driver update. Unzip this file to a directory you will remember, such as WINTV. It will create a new folder. To install, open the folder. Run HCWDRIVERINSTALL.EXE. This will install the WinTV-HVR base driver. At the completion of the driver install you should see a message which says Drivers have been updated.

Support for the digital functionality of this device was added to the 2.6.26 kernel.

• Where can I purchase Mac version Hauppauge Win TV-HVR-950 Hi all, When I look at all the dealers (retail and online) that Hauppauge lists as retailers of Hauppauge products I can't find the Mac version model # 1145.
• HVR 950 DRIVER FOR MAC DOWNLOAD - You can download a fully featured version of the product on a 30 day trial from www. If you have a WinTV v7. Note that Markus Rechberger maintains a version of tvtime that is patched to work around this limitation: By using our website, you are agreeing to the use of Cookies.

• 2Components used:
• 3Making it Work

Overview/Features

This device supports ATSC (i.e. OTADigital TV) and analog NTSC. It also has a connector on the side for an A/V cable dongle, however, such is not shipped with some versions of the device (though it apparently is in the case with the identical ElgatoEyeTV Hybrid US). The package includes a small dipole antenna and a short USB extension cable.

There may be slightly different versions of this device being sold -- internally the components are the same, but minor variances in the exterior shell casing. Models listed [1] include:

• model 01139: WinTV-HVR-950 with ATSC and NTSC tuners, and portable antenna
• model 01145: WinTV-HVR-950 for Mac's and PC's. For use in North America. Bundled with Elgato EyeTV Lite for Mac's and WinTV v6 for PC's
• model 01176: WinTV-HVR-950 with ATSC and NTSC tuners plus French/Englsh manual and portable antenna

Also see the HVR-950Q, released in Q1/08, which adds support for digital cable.

Components used:

• Xceive xc3028ACQ (tuner & analog demodulator)
• LG DT3303 (digital demodulator)
• Texas Instruments tvp5150 (video decoder)
• Empiatech em2883 (USB bridge and analog audio)

Identification

This descriptor is from a unit packaged as a 'WinTV HVR 950, model 1176', which is shipped with the A/V cables and toy-sized antenna but no remote:

Subsystem ID

Making it Work

Firmware

In order to use the LinuxTV driver, you need to download and install the firmware. Here is the procedure to follow (taken from the help found in extract_xc3028.pl):

Download the windows driver with something like:

Extract the file hcw85bda.sys from the zip into the current dir:

run the extract_xc3028.pl script found in linux/Documentation/video4linux:

copy the generated file so it can be picked up by the Linux kernel:

Hauppauge Wintv Hvr 950 Drivers For Mac Pro

Drivers

Use a recent snapshot of LinuxTV's v4l-dvb drivers

• Both analog and ATSC digital reception are supported
• Read the above mentioned Firmware section for details on installing the proper firmware.

Hauppauge Wintv-hvr 950

Analog Audio Issue

Analog audio appears to be problematic so you will likely need to employ SOX as a helper application, prior to starting the viewing app, in order to get any sound in popular apps like tvtime etc.

Hauppauge Wintv Hvr 850 Drivers

sox -r 48000 -w -c 2 -t ossdsp /dev/dsp1 -t ossdsp /dev/dsp

Note that there may be an associated delay (i.e. not in sync).

The root of the problem is that the em28xx presents itself as a USB audio device, and applications such as tvtime do not know to associate the video stream with the audio stream.

Note that Markus Rechberger maintains a version of tvtime that is patched to work around this limitation: Mcentral.de tvtime

Sample kernel output

provide the relevant portion of dmesg here

Remote Control Support

Hauppauge Wintv Hvr 1250

The WinTV-HVR950 package currently does not include a remote control. One may be available as an optional-extra upgrade; Support was added for the optional remote in the LinuxTV driver in hg version 9628 (November 16, 2008).
